【FJH】INSULATION FOR FIRELESS JOINT

E106-00002

【FJH】INSULATION FOR FIRELESS JOINT

Specifications

Material ・・・ Chemical cross-linked foamed PE

Insulation Thickness : 10mm

Donwload data

Contact Us

Details

fjh_fig_e.eps
Code number Model number Applicable Fireless joint model Length(mm) Applicable Fireless joint model Length (inch)
60874080481 FJH-2-3-20H FJ-635 FJ-952 142 FJ-635 FJ-952 5 5/8
60874080482 FJH-4-5-20H FJ-1270 FJ-1588 152 FJ-1270 FJ-1588 6
60874080483 FJH-6-7-20H FJ-1905 FJ-2222 169 FJ-1905 FJ-2222 6 3/4
60874080484 FJH-8-9-20H FJ-2540 FJ-2858 184 FJ-2540 FJ-2858 7 1/4
60874080485 FJH-10-20H FJ-3175 192 FJ-3175 7 5/8
60874080486 FJH-11-12-20H FJ-3492 FJ-3810 200 FJ-3492 FJ-3810 7 7/8
60874080512 FJH-2-3 FJ-635 FJ-952 142 FJ-635 FJ-952 5 5/8
60874080513 FJH-4-5 FJ-1270 FJ-1588 152 FJ-1270 FJ-1588 6
60874080514 FJH-6-7 FJ-1905 FJ-2222 169 FJ-1905 FJ-2222 6 3/4
60874080515 FJH-8-9 FJ-2540 FJ-2858 184 FJ-2540 FJ-2858 7 1/4
60874080516 FJH-10 FJ-3175 192 FJ-3175 7 5/8
60874080517 FJH-11-12 FJ-3492 FJ-3810 200 FJ-3492 FJ-3810 7 7/8
  • OBuild to order
  • EEnd production
  • SAs long as stock
