【RR】REDUCER

E302-00017

For Connection Between Different Sizes

【RR】REDUCER

Installation Materials for Air-Conditioners 2020 27

Contact Us

Contact Us
Office network

Details

Code number Model number Material Production A B C D E L（Acceptable length） Material Production A B C D E F G F G
60874084547 RR-300H-300-A-ZA ZAM - 447 225 140 260 416 120～220 ZAM - 17 5/8 8 7/8 5 5/8 10 1/4 16 1/2
60874084897 RR-900-600-A-ZA ZAM Special Order Only 447 225 140 360 416 220～320 ZAM Special Order Only 17 5/8 8 7/8 5 5/8 14 1/4 16 1/2
60874084907 RR-900H-600H-A-ZA ZAM Special Order Only 597 225 140 160 566 20～120 ZAM Special Order Only 23 5/8 8 7/8 5 5/8 6 3/8 22 3/8
60874085427 RR-300H-150-A-ZA ZAM - 597 225 140 260 566 120～220 ZAM - 23 5/8 8 7/8 5 5/8 10 1/4 22 3/8
60874085437 RR-300-150-A-ZA ZAM - 297 105 60 160 266 20～120 ZAM - 11 3/4 4 1/4 2 3/8 6 3/8 10 1/2
60874085447 RR-450-300-A-ZA ZAM - 297 105 60 260 266 120～220 ZAM - 11 3/4 4 1/4 2 3/8 10 1/4 10 1/2
60874085457 RR-600-300-A-ZA ZAM - 297 105 60 360 266 220～320 ZAM - 11 3/4 4 1/4 2 3/8 14 1/4 10 1/2
60874085467 RR-600-450-A-ZA ZAM - 447 105 60 160 416 20～120 ZAM - 17 5/8 4 1/4 2 3/8 6 3/8 16 1/2
60874085477 RR-450H-300-A-ZA ZAM - 447 105 60 360 416 220～320 ZAM - 17 5/8 4 1/4 2 3/8 14 1/4 16 1/2
60874085487 RR-450H-450-A-ZA ZAM - 447 225 140 160 566 20～120 ZAM - 17 5/8 8 7/8 5 5/8 6 3/8 22 3/8
60874085497 RR-600H-300-A-ZA ZAM - 445 225 140 360 566 220～320 ZAM - 17 5/8 8 7/8 5 5/8 14 1/4 22 3/8
60874085507 RR-600H-450-A-ZA ZAM - 597 225 140 160 866 20～120 ZAM - 23 5/8 8 7/8 5 5/8 6 3/8 34 1/8
60874085517 RR-600H-450H-A-ZA ZAM - 597 225 140 260 866 120～220 ZAM - 23 5/8 8 7/8 5 5/8 10 1/4 34 1/8
60874085527 RR-600H-600-A-ZA ZAM - 597 225 140 360 866 220～320 ZAM - 23 5/8 8 7/8 5 5/8 14 1/4 34 1/8
60874086937 RR-300-150-A-SUS Stainless Special Order Only 414 364 307 160 242 Stainless Special Order Only 16 3/8 14 3/8 12 1/8 6 3/8 9 5/8 141 121 5 5/8 4 7/8
60874086947 RR-450-300-A-SUS Stainless Special Order Only 564 514 462 310 242 Stainless Special Order Only 22 1/4 20 1/4 18 1/4 12 1/4 9 5/8 143 121 5 3/4 4 7/8
60874086970 RR-450H-300-N-SUS Stainless Special Order Only 564 514 462 310 242 Stainless Special Order Only 22 1/4 20 1/4 18 1/4 12 1/4 9 5/8 143 121 5 3/4 4 7/8
60874086987 RR-450H-450-A-SUS Stainless Special Order Only 564 514 462 310 362 Stainless Special Order Only 22 1/4 20 1/4 18 1/4 12 1/4 14 3/8 263 181 10 3/8 7 1/4
60874086990 RR-600H-300-N-SUS Stainless Special Order Only 564 514 462 310 362 Stainless Special Order Only 22 1/4 20 1/4 18 1/4 12 1/4 14 3/8 263 181 10 3/8 7 1/4
60874087007 RR-600H-450-A-SUS Stainless Special Order Only 242 204 156 - 202 Stainless Special Order Only 9 5/8 8 1/8 6 1/4 - 8 115 - 4 5/8 -
60874087017 RR600H-450H-A-SUS Stainless Special Order Only 242 204 156 － 202 Stainless Special Order Only 9 5/8 8 1/8 6 1/4 － 8 115 - 4 5/8 -
60874088957 RR-450H-300H-A-ZA ZAM - 714 664 612 400 242 ZAM - 28 1/8 26 1/4 24 1/8 15 3/4 9 5/8 139 121 5 1/2 4 7/8
60874088967 RR-600H-300H-A-ZA ZAM - 714 664 612 400 362 ZAM - 28 1/8 26 1/4 24 1/8 15 3/4 14 3/8 263 181 10 3/8 7 1/4
60874089087 RR-900-450-A-ZA ZAM Special Order Only 414 364 307 160 362 ZAM Special Order Only 16 3/8 14 3/8 12 1/8 6 3/8 14 3/8 263 181 10 3/8 7 1/4
60874089337 RR-900H-450H-A-ZA ZAM Special Order Only 1014 964 650 320 242 ZAM Special Order Only 40 38 25 5/8 12 5/8 9 5/8 143 121 5 3/4 4 7/8
  • OBuild to order
  • EEnd production
  • SAs long as stock
